Banana Plug Test Lead - 2mm, Stackable
$2.95 - $3.95
Description
The 2mm Stackable Banana Plug Test Lead is ideal for low-voltage testing and electrical connections. It features 2mm banana plugs with an exposed pin and no insulation, allowing convenient connections in suitable test and measurement setups. Available in 145mm, 265mm, and 475mm lengths to suit different application requirements.
Features
- 2mm stackable banana plug design
- Exposed pin with no insulation
- Designed for low-voltage applications
- Available in 145mm, 265mm, and 475mm lengths
- Suitable for test and measurement setups
- Provides flexible connection options
Specifications
Cable Type
Silicon, Highly Flexable
Cable Conductor
0.50mm² - copper stranded
Cable OD
2.5mm
Max Lead Current Rating
10A
Max Lead Voltage Rating
30VAC/60VDC
Full Range
| Size | Colour | Product Code |
|---|---|---|
| 145mm | Black | LE5915BLK |
| 145mm | Blue | LE5915BLU |
| 145mm | Green | LE5915GRN |
| 145mm | Red | LE5915RED |
| 145mm | Yellow | LE5915YLW |
| 265mm | Black | LE5930BLK |
| 265mm | Blue | LE5930BLU |
| 265mm | Green | LE5930GRN |
| 265mm | Red | LE5930RED |
| 265mm | Yellow | LE5930YLW |
| 475mm | Black | LE5950BLK |
| 475mm | Red | LE5950RED |
