12 Volt 5 Watt Monocrystalline Solar Panel 295x255mm

KI2091
Photo of a 12 volt 5 watt monocrystalline solar panel that is 295mm wide and 255mm tall.

$29.95

QTYPrice
1 $29.95
2 $27.00
5 $24.70

Description

These high performance monocrystalline solar panels are much smaller, thinner, higher in efficiency and more affordable than our previous models. The manufacturing process for this range uses 36 pieces of 156x156mm A-grade solar cells cut into defined sizes with 4 grid lines, which provides excellent performance under low light environments. Each panel is designed to withstand harsh environmental conditions with a durable anodised aluminium frame and 3.2mm low iron tempered glass. The glass is anti-reflective and has a hydrophobic effect to resist dirt and dust, improving light absorption thereby preventing any needless power loss. The anti-reverse charging diode in the junction box prevents the 12V battery to reverse charge solar panels in the night or when sunlight is low. The entire range is easier to install with minimal ongoing maintenance and compatible with industry standard inverters and mounting systems.

Specifications

Solar Panel

Cover Material

Tempered Glass

Open Circuit Voltage

21.5V

Short Circuit Current

0.32A

Voltage at Power Max

17.5V

Solar Panel Type

Monocrystalline

Mounting Method

Standard Universal

Mounting Material

Aluminium

Current at Power Max

0.29A

DC Voltage Rating

DC Voltage

12V

Power Rating

Continuous Power

5W

Dimensions

Length (mm)

245

Width (mm)

183

Height (mm)

18

Cable Length (m)

1
